02310MHS Huawei Compatible 40GBASE-LR4 QSFP+ 1310nm 10km LC DOM Transceiver Module
Product Description
|
Part Number
|
02310MHS
|
|
Model
|
QSFP-40G-LR4
|
|
Description
|
40GBase-LR4 Optical Transceiver,QSFP+,40GE,Single-mode Module(1310nm,10km,LC)
|
|
Attributes
|
Hardware
|
|
Category
|
Optical Transceiver
|
|
Product Line
|
Networking
|
|
Product Family
|
Switch
|
|
Product Category
|
Optical Transceiver
|
-
BASE-LR4 Quad Small Form-factor Pluggable Plus (QSFP+).
-
Standards based 40-Gigabit Ethernet (40GBASE-LR4).
-
40 Gbit/sec line speed.
-
Operating distance up to 10km on OS1 fibre.
-
Transmitter wavelength 1310nm.
-
Industry-standard LC connector.
-
Singlemode Fibre (SMF).
-
Digital Optical Monitoring (DOM).
-
Basic Information
Module name: QSFP-40G-LR4
Part Number: 02310MHS
Model: QSFP-40G-LR4
Form factor: QSFP+
Application standard: 40GBASE-LR4
Connector type: LC
Optical fiber type: SMF
Working case temperature [°C(°F)]: 0°C to 70°C (32°F to 158°F)
Transmission rate [bit/s]: 40 Gbit/s
Target transmission distance [km]: Single-mode fiber: 10 km
Transmitter Optical Characteristics
Center wavelength [nm]: 1271 nm, 1291 nm, 1311 nm, 1331 nm
Maximum Tx optical power [dBm]: 2.3 dBm
Minimum Tx optical power [dBm]: -7.0 dBm
Minimum extinction ratio [dB]: 3.5 dB
Receiver Optical Characteristics
Rx sensitivity [dBm]: -11.5 dBm
Overload power [dBm]: 3.3 dBm
