Electric Order Picker MHA series
Main Features:
MHA10 series:
1.The cover board with direction display, easy to know the driving direction even in high-order position;
2.The Vehicle have driving alarm,and safety belt, to ensure the safe driving;
3.Mast Buffering function;
4.The high level order picker including automatic high level order picker and semi-automatic high level order picker;
5.The Series High level order picker, rated load capacity: 1000kg, max lift height:4500mm;
6.With driving direction display, easy to know the direction even in high level;
7.With driving alarm and safety belt;
8.Mast with buffering function.
Specification:
|
Brand
|
|
MiMA
|
MiMA
|
|
Model
|
|
MHA1030
|
MHA1060S
|
|
Power Type
|
|
Battery
|
Battery
|
|
Operation Type
|
|
Stand-on
|
Stand-on
|
|
Service weight(incl. battery)
|
kg
|
2490
|
2830
|
|
Rated Capacity
|
Q(kg)
|
1000
|
1000
|
|
Load Center
|
C(mm)
|
500
|
500
|
|
Lifting height
|
h3(mm)
|
3000
|
6000
|
|
Forks size
|
l/e/s(mm)
|
1070/100/40
|
1070/100/40
|
|
Front Overhang
|
x(mm)
|
148
|
160
|
|
Turning radius
|
Wa(mm)
|
1625
|
1625
|
|
Max. climbing ability
|
%(tanθ )
|
/
|
/
|
|
Driving speed(load/unload)
|
km/h
|
4/4.8
|
4/4.8
|
|
Lifting speed(load/unload)
|
mm/s
|
110/125
|
110/125
|
|
Lowering speed(load/unload)
|
mm/s
|
310/260
|
310/260
|
Advantages:
●Advanced Curtis controller, more stable and safer.
●Maintenance-free AC drive system makes the vehicle react more quickly and accurately, and can be equipped with a full AC system.
●Pure electric steering, small steering force, comfortable and energy saving.
●The lifting system adopts proportional control, which has good start and stop smoothness and no jitter.
●Standard auxiliary lifting function, when the picking operation is carried out, the driver can be prevented from kneeling and the working intensity can be reduced.
●Standard turning speed limit and high lifting speed limit.
●Standard maximum lifting height limit.
Company Exhibition:
MiMA can offer you electric pallet truck, pallet stacker, reach stacker,reach truck,counter balance stacker,counter balance forklift, tow tractor, order picker, narrow aisle forklift, special forklift, AGV and other customized types for options, which can provide our customers with logistics handling solutions from 500kg to 100,000kg. Due to product serialization and standardization, all MiMA products are widely used in medicine, food, chemical, household electrical appliances, wool cotton textile, tobacco, electronics, machinery, furniture and many other industries.
Certification:
FAQ:
Q1: Are you electric order picker factory?
A1: Yes, we are the professional manufacturer of electric order picker for more than 20 years.
Q2: How about the delivery time?
A2: About 20-30 days based on different model. For some standard products, we may have stock and could delivery immediately.
Q3: Is customized solution available?
A3: Yes, we can provide different customized solution.
Q4: Can you provide OEM service?
A4: Yes.
