10-100T Electric Hydraulic Press Machine with Digital Pressure Controller
YLJ-100E is a electric hydraulic pressing machine up to 100 metric tons for preparing compound or ceramic sample faster and easier. YLJ-100E has built in electric hydraulic pump which is driven by electric oil pump with the digital pressure controller. Transparent protection shield around the machine is included with interlock It is an excellent tool for material/ceramic/chemistry laboratories to make larger pellet sample.
Specification
|
Pressure
|
·Max. 100 Metric Tons
·10 - 100 T adjustable by digital controller
·Pressure accuracy: +/- 1%
|
|
Electric Hydraulic Pump
|
·Standard: 110VAC - 240V AC ( single phase 。 50/60hz ) for worldwide use
·750 W AC motor
·Optional: 110V-220V transformer for using under 110V
|
|
Bottom Hydraulic Cylinder Travel Distance
|
0 - 30 mm
|
|
Top Support Screw Adjustable Height
|
320 mm
|
|
Working Space
|
·Top & Bottom working plate:: 300 mm x 250 mm
|
|
Protection Shield
|
·Thick plastic shields around the press with electric interlock
·Note: Must close door before operation
|
|
Net Weight
|
·500 Kg
|
|
Shipping Dimensions
|
48"(L) x 41"(W) x 42"(H)
|
|
Weight of Shipment
|
560 kg
|
|
Application Notes
|
·Check the Oil Level regularly using the included oil dipstick. Add AW 46 Hydraulic Oil if the Oil Level when low.
·The pressing die cannot be used for pressing powder with the particle size < 30 microns. Small particles may slip into the gap between pushing rod and steel sleeve and cause damages to the sleeve during the compression. Ball mill and sieve the powder and apply only the 32~75 microns power to the pressing die to avoid the damages. Please consider using the 3'' Dia. Sieve Set No.200&450 Mesh to separate the 32~75 microns particles from the powder clumps. Please clean the die via ethanol after the completion of each experiment.
·Do not raise the bottom cylinder (piston) more than it's maximum traveling distance. (50mm)
·Warning: Customers must always wear protection goggles during operation !!!
·For reasons of transportation or Idle for a long time, please tighten the nuts of the oil filling hole, which will affect pressurization.
·Operate the presser inside the glove box is not recommended
|
|
Compliance
|
·CE Certified
|
|
Press Dies (optional)
|
Pressing dies with various diameters are available upon request at extra cost
|
|
Warranty
|
Two years limited warranty with lifetime support
|
