Handheld laser welder speed is 4-10 times faster than the traditional TIG/MIG welding
-
Easy to operate, no need welding work license, unskilled operator can also weld products beautifully
-
Can weld metal products of different materials and thicknesses
-
Low welding heat, no deformation of the workpiece
-
Smooth and beautiful, which reduces the subsequent grinding process and saves time and cost by laser welder
|
|
Compare with Traditional Welding
|
|
|
Unskill worker can get started in 10 minutes,The welding speed is 4-10 times that of traditional welding, saving 3-5 professional welders. Concentrated energy, low thermal deformation, beautiful welding seam, deep penetration, high strength, can weld thin materials, can be welded by filler wire, or welded without wire.
|
High professional and technical requirements, high wages for workers, occupational diseases, large body injuries, slow welding speed, low efficiency, large heat influence and easy deformation, thick and irregular welds, requiring secondary polishing, large limitations, and can not weld too thin materials.
|
|
|
Traditional welding
|
Handheld Laser welding machine
|
Welding speed
|
Common
|
4-10x faster
|
HeatAffected zone
|
large
|
small
|
Deformation
|
large
|
small
|
Bond strength with base material
|
Common
|
Excellent
|
Subsequent processing
|
Polish
|
No or very little polish
|
Consumables
|
any
|
Little
|
Operation difficulty
|
Complicate
|
Simple
|
Operator safety
|
Not safe
|
Safe
|
Impact on the environment
|
Pollutional
|
Enviromental
|
Welding fault tolerance
|
Good
|
Good
|
Pendular welding
|
No
|
yes
|
Adjustable spot width
|
No
|
Yes
|
Welding quality contrast
|
Bad
|
Excellent
|
Adjustable Welding mode
|
No
|
Six Mode
|
|
|
PES-W1000 Laser Welding Capacity
Material
|
Thickness
Single side weld
|
Thickness
Double side weld
|
Thickness
Wire weld
|
Sianless steel
|
3mm
|
6mm
|
2.5mm
|
|
Galvanized steel
|
3mm
|
6mm
|
2.5mm
|
|
Mild steel
|
3mm
|
6mm
|
2.5mm
|
Titanium alloy
|
3mm
|
6mm
|
2.5mm
|
|
Aluminum
|
2mm
|
4mm
|
1.8mm
|
|
Copper
|
1mm
|
2mm
|
0.8mm
|
|
|
