1000w 12v 24v 48vdc to 110v-220vac off grid pure sine wave inverter

DC input 12V 24V 48V

AC ouput 100-240V/50Hz or 60HZ inverter

Conversion efficiency up to 90%

Low interference technology

Soft start function

Same size, light weight, faint noise ,free maintenance

High converting  efficiency

Under voltage shutdown protection

Over voltage shutdown protection

Latest soft-start technique

Overload protection

Overheat protection

Alloy aluminium case



What is a power inverter?

A power inverter is a device which converts battery output (DC, or direct current) into 230V AC mains electricity (alternating current). 230V AC is the type of electricity supplied by utility companies to run standard domestic appliances such as a TV, fridge, radio, lights or to charge a laptop / mobile phone etc. If you have a battery, connecting a power inverter will enable you to power household appliances in areas with no access to mains electricity; such as in a motorhome, caravan, boat, farm or any other remote location. Inverters are also perfect for off-grid and back up systems for accidental power cuts.


This is a pure sine wave type of inverter, which means that the 230V AC output harmonically follows a smooth sine wave and is almost identical to normal mains electricity. Pure sine wave output is far superior than square sine wave or modified sine wave output for running appliances. This is because:


- It is suitable for a broader range of appliances (for example, appliances with electric motors can not be powered by modified sine wave inverters)
- It is more efficient compared to modified sine wave inverters.


This 1000W 12V pure sine wave power inverter can generate 1000W of continuous power and up to 2000W of power at peak times (peak time reserve capacity is useful if more energy is required to start an appliance than for its continuous running).


This product comes with important protection and safety features, such as over-discharge, overload, overheating and short-circuit automatic shutdown.


There is also a USB port which can be used for charging mobile phones, tablets, laptops, MP3 players and other USB-compatible devices.


Which appliances can be powered?

If you are unsure whether 1000W is sufficient for your appliances, please see more details on the right.


Product Parameters:

OUTPUT OUTPUT VOLT 100/110/120/220/230/240VAC
CONTINUOUS POWER 1000W
SURGE POWER 2000W
WAVEFORM PURE SINE WAVE
FREQUENCY 50Hz/60Hz
AC REGULATION LOW & HIGH 10%
Non-load  Consumption <10W
EFFICEINCY >90%
INPUT USB OUTPUT 5V
DC VOLTAGE LED DISPLAY POWER & FAIL STATUS
INPUT RANGE 10-15V      21-30V      40-60V
PROTECTION WORKING INPUT 12V            24V          48VDC
FUSE 25A           20A           15A
Low battery alarm 10.5±0.5V   21+0.5V    42+0.5V
Low battery shut down 10±0.5V       20+0.5V    40+0.5V
Over voltage shut down 15.5±0.5V   30.5+0.5V   60+0.5V
Over load shut down 1200W over 10 seconds
Over heating shut down >75
Over Thermal  shut down the output
Working Temperature BETWEEN -10 and +50
soft start
OTHER DIMENSION(L*W*H)  305*146*66mm
INNER BOX DIMENSION  360*185*115mm
CARTON DIMENSION  495*195*380mm
NET WEIGHT 2.8±0.2KG
GROSS WEIGHT 13±1KG
PACKING 4PCS/CTN
