EC-G06S5-SY H.265 Cashier Camera
2MP HD Cashier Camera permits close monitoring and recording all actions happening in a cash counter.
Product information
Image sensor:1/2.7″CMOS
Video resolution:1920×1080
Pixel:2.0MP
Compression:H.265/H.264/JPEG
Frame rate:up to 20fps
Video bit rate:204Kbps～6Mbps adjustable
Lens
Manual Focus:6mm,8mm
Features
Auto exposure:Support
Auto gain control:Support
Auto white balance:Support
3D DNR:Support
OSD information setting:Support OSD big font function , OSD and time can be set separately
Network timing:Support
QR code scan:Support to create the QR code and scan to add equipment
Timing restart:Support
Intelligent fog removal:Support
ROI coding:Support ROI enhancement coding and enhancement exposure
Privacy masking:Can mask 4 areas at the same time
Motion detection:Support
Image setting:Contrast, Brightness, Saturation, Acutance are adjustable
Scene switching:Support 4 scene switches: indoor, outdoor, default and soft
Day and night function:ICR auto switch
Screen setting:Support exposure time setting
Night vision optimization:Support
Software WDR:Support
Picture setting:Mirror image, reversal image
IP adaptive technology:Support automatically adapt IP address optional function
Detection alarm:Email alarm push, clients alarm push
Remote control:System management, Bit stream management, User management, Network management
External extended interface:Audio Input
Network
Network:1 RJ45 10M/100Mbps self-adaptable Ethernet port
Video coding:1080P, 720P, Internet
Network Protocol:HTTP,TCP/IP,ICMP.RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP,DNS,PPPOE
Control protocol:ONVIF
Web Browser:Support IE8+,Chrome18+,Firefox5.0+,Safari5.02+ . Support Chinese and English
Preview video:32 CH at the same time
User rights:Administrator, Ordinary user, Visitor
Other Features
Power supply:DC 12V
Operating Temperature:-20℃~+60℃
Operating Humidity:10%~90%
Power consumption:Daytime: ＜3W; Night: ＜6W
Color / Material:Metal
Size(W×H×D)(mm):130*60*60mm
Weight:261g
