ES31X-3LCD02
10Gbps 1310nm
MM 220M SFP+ Optical Transceiver
Features
Supports 9.95 to 10.3Gbps bit rates
Transmission distance up to 220m (OM1 fiber)
Hot Pluggable SFP+ footprint
1310nm FP transmitter, PIN photo-detector
Digital Status monitoring Interface
Duplex LC connector
RoHS compliant and Lead Free
Metal enclosure for lower EMI
Single 3.3V power supply
Power dissipation < 1W
Operating case temperature: 0 to 70℃
Compliant with FC-PI-4 800-Mx-SN-I, SFF-8431 , SFF-8432 and SFF-8472
Applications
10GBASE-LRM 10G Ethernet
Legacy FDDI multimode links
Standard
Compliant with SFF-8472 SFP+ MSA.
Compliant to SFP+ SFF-8431 and SFF-8432.
Compliant to 802.3ae 10GBASE-LRM.
RoHS Compliant.
Product description
ETU-Links’ SFP+ LRM is an optical transceiver module for transmission at 1310nm over legacy multi mode fiber. Supporting
10GBASE LRM Ethernet standard make it ideally suited for 10G datacom. Its very low power consumption and its excellent EMI performance allow system design with high port density. The small form factor integrates a 1310nm
Fabry-Perot (FP) laser in an LC package and a linear multimode PIN receiver. ETU-Link module is lead free, RoHS compliant and is
designed and tested in accordance with industry safety standards.
The ETU-Link GPP-31192-LRMC SFP+ transceiver is a linear-interface transceiver that enables,inconjunction with an Electronic
Dispersion Compensation (EDC) on the host board, an IEEE802.3 aq 10GBASE-LRM compliant link. The host board EDC provides
correction for the severe modal dispersion that may occur during propagation through multimode fiber links, including legacy
installed FDDI multimode fiber (see IEEE802.3aq for detailed information regarding fiber coverage).
