10kV European Type Cable Branch Box DFW Series

The European-Style Cable Branch Box is a specialized solution for 10kV cable-based power distribution systems, offering fully insulated, sealed, and shielded construction for enhanced safety and reliability. Its robust design ensures optimal performance in commercial centers, industrial parks, high-traffic urban areas, and harsh outdoor environments. With flexible installation options, it simplifies power distribution and reduces maintenance needs, making it an ideal choice for modern grid infrastructure upgrades.

Facebook Twitter Pinterest LinkedIn 分享

Description

DFW Series 10kV European Type Cable Branch Box Features

Compact and Versatile Design

Fully insulated, sealed, and shielded structure, requiring no external insulation distance, ensuring safety and reliability.
Durability in Harsh Environments
Dustproof, waterproof, corrosion-resistant, and maintenance-free, making it suitable for a variety of challenging outdoor conditions.
Flexible Connectivity
Supports up to 6 branch connections, allowing for easy integration with diverse wiring configurations.
Safety & Protection
Equipped with a built-in live line indicator for real-time monitoring of power status and an optional short-circuit fault indicator for quick fault detection.
Customizable Options
Available in multiple enclosure materials and colors (standard options are military green and gray), with customization available to meet user requirements.

Specifications

Rated Voltage	10kV
Maximum Operating Voltage	12kV
Rated Frequency	50Hz
Rated Current	630A
Power Frequency Withstand Voltage(1min)	42kV
Lightning Impulse Withstand Voltage	75kV
Rated Thermal Stability Current	20kA/2s
Enclosure Ingress Protection Rating	IP33
