10mm Width High Temperature KAPTON Tape For Lithium Battery Electrode Fixed And Strapping



SPECIFICATION

This hot melt adhesive/sealant is specific and necessary item for sealing tab (Nickel or Aluminum) in between aluminum-made lamination film (pouch cell case).

Model	TMAX-W-TTP
Color	Milk-White
Thickness	100 um
Width	4mm, 5mm, 6mm, 7mm, 8mm,10mm, Customized width
Length	100m for 1 roll
Material	Enhanced Sulfurized Polymer Resin Material (3 Layers  Lamination)
Outside Layers (Both Sides)  Thermal Softening Index	116ºC/ 3 Seconds/ 0.3Mpa/ 180ºC (Reference only)
Outside Layers  (Both Sides) Thermal Melting Index	135ºC/ 3 Seconds/ 0.3Mpa/ 180ºC (Reference only)
Middle Layers (Both Sides)  Thermal Softening Index	145ºC/ 3 Seconds/ 0.3Mpa/ 180ºC (Reference only)
Middle Layers (Both Sides)  Thermal Melting Index	175ºC/ 3 Seconds/ 0.3Mpa/ 180ºC (Reference only)
Removal Strength from Tab	> 15N/15mm
Removal Strength from  Al Lamination Film (Cell Case)	> 35N/15mm
Resistance to LiPF6 Solution (1:1:1)	No Change in the Solution @ 85ºC*24 Hours
