This is a full color animated laser lamp designed for bar matrix effects. Control system designed for large control table tiger, MA controller design, edit simple and flexible, mysterious color light beam of the movement, in the air to form rbis, sector, such as tunnel of time and space effect and more than 200 kinds of dynamic memory vivid pattern effect, more than one online powerful visual impact, is a high cost performance of laser bar matrix.
● Power: AC90-240, 50-60HZ
● Rated power: less than 200W
● Laser power: RGB10W
● Laser wavelength: 638nm red, 520nm green, 450nm blue
● Laser type: imported semiconductor solid-state laser Beam diameter / divergence angle: <5mm and <2.0mrad
● Scanning system: 30KPPS high-speed galvanometer scanning system, scanning
angle ± 30 °
● Laser modulation signal: TTL modulation
● Control mode: International standard ILDA control / DMX512 signal control (6 /25CH) / self-propelled / sound controlled / master-slave (optional)
● Control interface: International ILDA DB25 interface, international universal DXM512 interface, can be connected to American pangolin, German fire Phoenix and other laser software and tiger, pearl, MA and other consoles
● Laser pattern: There are 128 laser effect patterns built in the motherboard. Laser effects: rotate, flip, move, zoom, fade, wave, change color, change size, etc.
● Safety and intelligence: a light-blocking light function, no signal blocking light, etc.
● Cooling system: forced cooling by fan
● Working environment: indoor (-10-35) degrees, such as outdoor use need to add waterproof equipment
● Suitable places: bars, night clubs, theaters, TV stations, concerts, stage
performances, etc.
● Net weight of lamp: 8.0KG
