1100 ℃ atmosphere chamber furnace

1100 ℃ atmosphere chamber furnace



1100 ℃ atmosphere chamber furnace


SPECIFICATIONS



TYPE

TOB-DSP-GF1100-I

TOB-DSP-GF1100-II

TOB-DSP-GF1100-III

TOB-DSP-GF1100-IV

TOB-DSP-GF1100-V

TOB-DSP-GF1100-VI

TOB-DSP-GF1100-VII

Power

2.5KW

4KW

5KW

9KW

16KW

18KW

32KW

Furnace tube size(mm)

300*200*120

300*200*200

300*250*250

400*300*300

500*400*400

500*500*500

800*600*600

Dimension

500*540*665

520*610*765

580*610*885

700*700*880

810*850*1060

940*970*1300

1110*1050*1400

Power supply voltage

220V

380V

Phase number

Single-phase

Three Phase

Temperature control mode

I. Yudian temperature control

30 sections can only use PID temperature regulation.

II. FP93 temperature control (from Japan)

(Replace imported instruments, for an additional fee)

1,40 section program temperature control can be divided into 4,2,1 group program,

 if the program is divided into four groups, each program segment 10,

2,6 group PID control, low, medium and high temperature can each with a set of PID,

 such that each segment is capable of controlling the temperature is very accurate.

Control accuracy

+/- 1 ℃

Triggers

Phase-shift trigger

SCR

106 / 16E Germany Semikron

Max temperature

1100℃

Rated temperature

1000 ℃

Heating rate

≤20 ℃ / Min (available upon request modification)

Recommended heating rate

≤15 ℃ / Min



Thermocouple Type

Type K

Certification

CE

Surrounding surface

temperature

≤45℃
