1100 chamber furnaces mini
SPECIFICATIONS
|
Model
|
TOB-DSP-KF1100 Mini
|
|
Power
|
1200W
|
|
Furnace tube size(mm)
|
100X100X100（DXWXH）
|
|
Dimension
|
250X200X380 (DXWXH)
|
|
Power supply voltage
|
220V
|
|
Phase number
|
Single-phase
|
|
Heating element
|
Resistance wire
|
|
Control mode
|
Yudian temperature control
30 sections can only use PID temperature regulation.
|
|
Temperature control mode
|
Intelligent PID
|
|
Over-temperature protection
|
Have
|
|
Overcurrent protection
|
Have
|
|
Break protection and display
|
Have
|
|
Furnace volume
|
1L
|
|
Furnace material
|
Polycrystalline alumina fibers (imported from Japan)
|
|
Control accuracy
|
+/- 1 ℃
|
|
Max temperature
|
1050 ℃
|
|
Rated temperature
|
1000 ℃
|
|
Thermocouple Type
|
Type K
|
|
SCR
|
A triac
|
|
Surrounding surface temperature
|
≤45℃
|
