1200x1920 resolution 10.1 inch IPS lcd display with mipi interface

1200x1920 resolution 10.1 inch IPS lcd display with mipi interface




Facebook Twitter Pinterest LinkedIn 分享

1200x1920 resolution 10.1 inch ips lcd display with mipi interface



Specification
LCD type 10.1 inch ips display
Display type 10.1 inch TFT, 16.7M color, normally black
Driver element color active matrix thin film transistor
Viewing angle
 All
Outline Dimension(mm) 143.10(W)*228.60(H)*2.50(T)
Active Area.(mm) 135.36(H)x216.576(V)
Resolution(dots) 1200xRGBx1920
Operating Voltage
 3.3V
Operating temperature(°C) -20-70
Storage temperature(°C) -30-80
Pixel arrangement  RGB Vertical Stripe
Display mode Normally white
Luminance(cd/m2) 250(typ.)
Contrast Ratio 500(typ.)
Application Notebook, advertisement display, etc.
Number of pins
 40
Interface  MIPI
Module lifetime(Hours) 50,000-100,000
