| Basic Specification |
Model and Body Structure |
BJ6122 / Semi-Monocoque |
Luggage Compartment（M³） |
10 |
| Exterior Dimensions（MM） |
12000×2550×3790 |
Approach/Departure Angle(°) |
8/9 |
| Driver Location |
Left-Hand Drive |
Min. Ground Clearance （MM） |
175 |
| Front/Rear Overhang (MM) |
2620/3380 |
Wheelbase ( MM ) |
6000 |
| Inner Height(MM) |
2010 |
Wheel Track （Front/Rear)（MM） |
2045/1870 |
| Kerb W(T) |
13.8 |
Max. Gross Weight(T) |
18 |
| Seats No. |
51+1+1 |
Inner Noise |
≤72 DB |
Engine
|
Model/Brand
|
Weichai engine WD615.46
|
Rated Power(kw/rpm)
|
275/2100
|
Emission/Displacement
|
EuroII / 9.726 L
|
Engine Location
|
275/2100
|
Chassis
|
Transmission
|
Manual, Fast brand, 6DS180T
|
Retarder
|
Terca Retarder
|
Front Axle
|
Fangsheng 6.5T
|
ABS
|
WABCO ABS
|
Rear Axle
|
Fangsheng 13T
|
Fuel Tank Capacity
|
520L
|
Steering
|
Imported Integral Power Steering
|
Automatic Clearance Adjuster
|
Automatic Clearance Adjuster
|
Braking
|
Front Disc And Rear Drum Brake
|
Tyre ＆ Hub
|
Double Coin 295/80R22.5, With One Spare Tire
|
Suspension Structure
|
Leave Spring Suspension
|
|
|
Body Specification
|
Front Passenger Door
|
Single Layer And Sealed
|
Battery
|
2*195Ah
|
Middle Passenger Door
|
With
|
Visual and Audio System
|
Long LED Lights
|
Front Windshield
|
Laminated Glass, Colorless
|
Ordinary Headlight
|
Rear Windshield
|
Tempered Glass
|
Electronic Clock
|
Thermometer
|
Side Window
|
Sliding Window, Light Grey Color
|
Back-up Monitor System
|
Hard Disk Player
|
Driver Window
|
Sliding Driver Windowsh
|
Back-up Monitor System
|
Front 19" Fixed LCD Screen；Middle 19" Foldable LCD Screen
|
Exterior Rear-view Mirror
|
Double Rabbit-Ear Type, Electric With Defroster
|
Microphone
|
Luggage Rack
|
Luggage Rack Bilateral
|
7"Colorful Monitor Screen, With 2 Cameras For Middle Passenger Door And Rear Of The Bus
|
Air Outlet
|
Air Outlet For Reading Lamp
|
Dynamo
|
Double 150A Dynamotor
|
Roof Hatch
|
2 Roof Hatch With Ventilation
|
A/C
|
Songz 31000 Kcal, Bizzer Compressor
|
Floor Leather
|
Antislip Floor Leather |
Defroster
|
Natural Wind Defroster
|
Passenger Seat & Seat Inclosure
|
51 Fabric Seats, Adjustable, Reclining, Two Point Saft Belt
|
Fire Extinguisher
|
Dry Powder Extinguishers
|
Driver Seat
|
Mechanical Damping Driver Seat
|
Safety Hammers
|
Anti-Theft Alarm Safety Hammers
|
Guide Seat
|
High Back Guide Seat With Two Points Safe Point
|
Paint
|
As Per Customer's Design
|
Side Curtain
|
With
|
Others |
Automatic Fire Extinguisher Device In The Engine Compartment
|
Driver Side Curtain
|
Driver Window Self-Locking Driver Sun-Visor
|
Engine Compartment Temperature Alarm Device
|
Sun-Visor
|
Double Manual Sun-Visor
|
|
|
