Technical Specifications for 1336-BDB-SP34D
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Output power
|
7.3 kW
|
|
Part Number/Catalog No.
|
1336-BDB-SP34D
|
Installation
|
Panel Mount
|
|
Module Type
|
Gate Drive Board
|
Input Voltage
|
320-450VAC
|
|
Manufacture Year
|
2021
|
Voltage Rating
|
12 VDC
|
|
Product Package
|
Original Package
|
UPC
|
15614598003015
|
About 1336-BDB-SP34D
|
The 1336-BDB-SP34D is an integral component of the drive’s circuit board platform, and it can be installed safely via the following steps (1) Attach the Gate Driver Board to the Main Control Board Mounting Plate, (2) Turn the 8 supplied fastening screws in a ¼ clockwise direction to fastening the Gate Driver Board to the Main Control Board Mounting Plate, (3) Connect the Main Control Mounting Plate with the attached gate driver board to the circuit board platform, (4) Connect the J2, J7, J8, J9, J10, and the J13 jumper connectors on the Gate Drive Board to connectors from the main control board, (5) Connect the Terminal Strip TB4 24V DC Auxiliary Input, (6) Connect the +DC/–DC Brake Terminals, (7) Turn on the Drive Power.
Installed on the 1336-BDB-SP34D Gate Driver Board is always tested for perfect working conditions whenever modules have been replaced, and it is tested for viability using a test meter to test Fuses 1 and 3 for open conditions, and by setting the test meter to the Diode mode, VR1 to VR6 component is tested and the reading compared to the standard table reading.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
