Technical Specifications for 1394C-AM75-IH
Manufacturer Automation
Brand
Part Number/Catalog No. 1394C-AM75-IH
Product Line Servo Controller
Module Type Servo (Axis) Amplifier
Output Rating 23.8 Kilowatt
DC Input Voltage 530-680
Amperage 35 A
Series Enhancements Filtering (EMI) and Enhanced Terminations
Heat Sink Options Inside Cabinet Heatsink
Capacitance 660 Microfarads
Speed Regulation 0-0.05% of base speed w/ 100% torque disturbance
Static Gain 22.8 rms A/mV
Continuous Current (rms) 35.0 Amperes
Peak Current (rms - 1 sec) 50.0 Amperes
Continuous Power 380/460 Volts 17.8/23.8 Kilowatts
Peak Power 380/460 Volts 25.4/34 Kilowatts
