1400 ℃ atmosphere chamber furnace

1400 ℃ atmosphere chamber furnace



1400 ℃ atmosphere chamber furnace


SPECIFICATIONS



TYPE

TOB-DSP-GF1400-I

TOB-DSP-GF1400-II

TOB-DSP-GF1400-III

TOB-DSP-GF1400-IV

TOB-DSP-GF1400-V

TOB-DSP-GF1400-VI

Power

4KW

6KW

8KW

10KW

13 KW

18KW

Furnace tube size(mm)

160X150X150

200X200X200

300X200X200

300X250X250

400X300X300

500X400X400

Dimension

550X470X 790

600X 510X840

600X 610X840

650X610X890

700X700X940

1000X1040X 1700

Power supply voltage

220V

380V

Phase number

Single-phase

Three Phase

Heating element

Silicon carbon rod

Temperature control mode

一.Yudian temperature control

30 sections can only use PID temperature regulation.

二.FP93 temperature control (from Japan)

(Replace imported instruments, for an additional fee)

1,40 section program temperature control can be divided into 4,2,1 group program,

if the program is divided into four groups, each program segment 10,

2,6 group PID control, low, medium and high temperature can each with a set of PID,

such that each segment is capable of controlling the temperature is very accurate.

Control accuracy

+/- 1 ℃

Triggers

Phase-shift trigger

SCR

106 / 16E Germany Semikron

Max temperature

1400℃

Rated temperature

1350 ℃

Heating rate

≤20 ℃ / Min (available upon request modification)

Recommended heating rate

≤10 ℃ / Min



Thermocouple Type

Type S

Certification

CE

Surrounding surface temperature

≤45℃
