The Quantum 140ACO02000 Analog Output Module controls and monitors current in up to (4) 4…20 mA loops.
This module has broken wire detection. Unused channels will indicate broken wire status unless wired to the loop supply as shown on channel 4 in the wiring diagram to the left (loop supply must be 30V or less).
A Quantum removable terminal strip allows for easy maintenance.
All Quantum I/O modules are optically isolated from the bus, ensuring safe and trouble-free operation. This isolation also allows modules to be hot swapped.
|
Module Type
|
|
4 Analog Outputs
|
|
|
|
|
|
Signal Type
|
|
4…20mA
|
|
|
|
|
|
Loop Voltage
|
|
12 … 30 VDC, up to 60 VDC with external resistor
|
|
|
|
|
|
Internal Voltage Drop
|
|
7 VDC min, 30 VDC max @ 20mA
|
|
|
|
|
|
Update Time
|
|
3 ms for all channels
|
|
|
|
|
|
Settling Time
|
|
0.9 ms to +/- 0.1% of the final value
|
|
|
|
|
|
Channel to Channel Isolation
|
|
500 VAC @ 47…63 Hz or 750 VDC for 1 minute
|
|
|
|
|
|
Channel to Bus Isolation
|
|
1780 Vac for 1 minute or 2500 VDC for 1 minute
|
|
|
|
|
|
Accuracy Error at 25 deg C
|
|
+/- 0.2% of full scale
|
|
|
|
|
|
Accuracy Drift with Temperature
|
|
Typical: 0.004% of full scale / ºC.
|
|
|
|
Maximum: 0.007% of full scale / ºC
|
|
|
|
|
|
Power Dissipation
|
|
5.3 W
|
|
|
|
|
|
IO Map
|
|
4 Output words
|
Schneider 140ACO02000
140ACO02000 | Analog Modules by Modicon Quantum
Email:sales3@amikon.cn
Range of product
|
Modicon Quantum automation platform
|
Product or component type
|
Analogue output module
|
