JNDX150A 24V to 240V photovoltaic battery charge regulator
Product Features:
JNDX series controller is designed according to the latest technology development, represents the latest photovoltaic technology level,with excellent performance:
-
Common cathode circuit design makes the system more stable and reliable.
-
High efficient PWM charging ways.
-
Variety of load control method, enhanced the flexibility of the system
-
Battery charging parameters can be set up.
-
Any combination of photovoltaic module and storage battery reverse automatic protection function, no damage to any device.
-
Adopt traditional LCD liquid crystal display and keyboard design, convenient to view the running parameters of the controller.
-
Provide industrial generic RS232 communication interface, user can design PC communication software, also can buy the company developed the upper machine communication accessories.
General Description:
The solar charge controller is the intelligent device with integration of controlling. It has good running performance with LCD display and convenient operation. Also have multi protection functions such as over-charge, over-discharge protection, and pole-confusion protection for storage battery. The controller is adopted PWM charging mode. It has high reliable and safe operation, high efficiency, long service life functions.
Parameters:
table:8-1
|
Electrical parameter
|
parameter
|
|
rated system voltage
|
DC
240V
|
DC
220V
|
DC
216V
|
DC
192V
|
DC
120V
|
DC
110V
|
DC
96V
|
DC
48V
|
DC
24V
|
|
Rated charge current
|
150A
|
150A
|
150A
|
150A
|
150A
|
150A
|
150A
|
150A
|
150A
|
|
The maximum allowable voltage
|
DC
320V
|
DC
293V
|
DC
288V
|
DC
256V
|
DC
160V
|
DC
147V
|
DC
128V
|
DC
64V
|
DC
32V
|
|
Max input voltage
|
DC
450V
|
DC
430V
|
DC
430V
|
DC
400V
|
DC
250V
|
DC
230V
|
DC
200V
|
DC
100V
|
DC
50V
|
|
Min input voltage
|
DC
300V
|
DC
275V
|
DC
270V
|
DC
240V
|
DC
150V
|
DC
138V
|
DC
120V
|
DC
60V
|
DC
30V
|
|
Max input power
|
36000
|
33000
|
32400
|
28800
|
18000
|
16500
|
14400
|
7200
|
3600
|
|
Static loss
|
<0.2A
|
|
Charge loop drop
|
≤0.5V
|
|
Discharge circuit of pressure drop
|
≤0.3V
|
Table:8-2 Battery voltage (Temperature：25℃)
|
controls parameter
|
|
Over voltage switching off
|
320V
|
294V
|
288V
|
256V
|
160V
|
147V
|
128V
|
64V
|
32V
|
|
limited charge voltage
|
300V
|
275V
|
270V
|
240V
|
150V
|
138V
|
120V
|
60V
|
30V
|
|
Over voltage Recover
|
294V
|
270V
|
265V
|
235V
|
147V
|
135V
|
118V
|
59V
|
29.5V
|
|
Average voltage
|
290V
|
266V
|
261V
|
232V
|
145V
|
133V
|
116V
|
58V
|
29V
|
|
Boost voltage
|
276V
|
253V
|
248V
|
221V
|
138V
|
127V
|
110V
|
55.2V
|
27.6V
|
|
Float voltage
|
250V
|
229V
|
225V
|
200V
|
125V
|
115V
|
100V
|
50V
|
25V
|
|
undervoltage recovery
|
216V
|
198V
|
194V
|
173V
|
108V
|
99V
|
87V
|
43.2V
|
21.8V
|
|
Under voltage disconnect
|
——
|
|
Duration of equilibrium
|
2 hours
|
Note: The table 8-2 can be set up on behalf of
this keypad and LCD Settings, all parameters can be set through the
communications software
Environmentalparameter 8-3
|
Environmental parameter
|
parameter
|
|
Work temperature
|
-35℃- +55℃
|
|
Store Temperature
|
-35℃- +80℃
|
|
Temperature Range
|
10%-90%No condensation
|
|
Protection level
|
IP30
|
|
Using altitude
|
≤3000m
|
|
Dimension
|
355*273*142(mm)
|
|
Hole Size
|
295mm x 353mm
|
|
Hole size
|
Φ7
|
|
Terminal
|
24mm2
|
|
Net weight
|
7.1kg
|
|
Dimension
|
355*273*142(mm)
|
