1734-4IOL POINT I/O 4 Channel I/O-Link Master Module
|
Topic
|
Page
|
|
Summary of Changes
|
1
|
|
About the Module
|
4
|
|
Install the Mounting Base
|
6
|
|
Install the Module
|
6
|
|
Install the Removable Terminal Block
|
7
|
|
Wire the Module
|
8
|
|
Communicate with Your Module
|
10
|
|
Interpret Status Indicators
|
11
|
|
Specifications
|
12
|
|
Additional Resources
|
14
|
The POINT I/O™ 4 channel IO-Link master module provides four channels that can be individually configured as IO-Link master or as a standard digital I/O module. The IO-Link channel master module can be configured to fit any IO-Link and/or discrete application.
In IO-Link mode, the module supports four channels for IO-Link master communication with IO-Link compatible devices. In standard digital I/O mode, the module supports four channels of digital input or output. Standard digital input channels support IEC61131-2 type 1 input. Channels can also be disabled if not in use.
You must use this module with the following:
• 1734-AENT or 1734-AENTR, Series B EtherNet/IP™ adapters with firmware revision 5.012 or later
• 1734-AENT or 1734-AENTR, Series C EtherNet/IP adapters with firmware revision 6.011 or later
• Studio 5000 Logix Designer® application, version 20 or later
