1746-IA16 Allen Bradley SLC-500 Allen Bradley Digital Input Module

Name: Allen Bradley Module Model: 1746-IA16
Warranty: 1 Year Gross Weight: 2.2 Lbs / 35.25 Oz / 1kg
Packing Size: 10.0" X 4.0" X 6.0" (25.4 Cm X 10.2 Cm X 15.2 Cm) Quality: New And Original
Package: Original Package Shipping Term: UPS,TNT DHL FEDEX
Lead Time: In Stock
High Light:

1746-ia16 allen bradley

SLC 500 Allen Bradley Digital Input Module

allen bradley slc 500 plc cpu





1746-IA16 Allen Bradley Controls SLC-500 Digital Input Module Allen Bradley PLC



Product Details:

Brand Name Allen Bradley
Model 1746-IA16
Series SLC 500
Condition New
Gross Weight 2.2 lbs / 35.25 oz / 1kg
Packing Size 10.0" x 4.0" x 6.0" (25.4 cm x 10.2 cm x 15.2 cm)
Country of Origin USA
Lead Time In Stock
Shipping Port Xiamen
Payment T/T
Sales Price Inquiry
Color Depends on material
Warranty 12 months
Lead time 5-8 work days
Courier partners DHL, UPS, TNT, FedEx and EMS



Additional Information:

The Allen-Bradley 1746-IA16 digital input module is a member of the SLC-500 family of processors. The 1746-IA16 has 16 input points and operates with a voltage category of 100V or 120V AC input signal. The 1746-IA16 has 16 points per common and its operating voltage is 85-132V AC at 47-63Hz. In addition, the 1746-IA16’s backplane current consumption is 0.085A at 5V DC and 0A at 24V DC.





The maximum signal delay for the ON and OFF states is 35ms and 45ms, respectively. The 1746-IA16’s maximum off-state voltage is 30V AC, its maximum off-state current is 2mA, and its input current is 12mA at 120V AC nominal. The maximum inrush current for the 1746-IA16 is 0.8A while the maximum inrush current time lasts for 0.5ms.



You can use a current limiting resistor for limiting the inrush current. This resistor will change the operation of the 1746-IA16 AC module. AC input devices, e.g. the 1746-IA16, needs to be compatible with the SLC-500 input circuit inrush current. It operates optimally at temperatures between 0 and 60 degrees Celsius.



Dimension wise, the 1746-IA16 measures 13cm x 5cm x 15cm. The 1746-IA16 is manufactured for use with programmable controllers. It is KCC, MARINE-ABS, C-Tick, MARINE –BVS, MARINE GL, MARINE –LR, CE marked and MARINE –DNV-certified.



The 1746-IA16 is intended for mounting on a chassis which has an open enclosure. It has a 500 VDC isolation on communication channels and 1500V AC backplane isolation. At 10-2000Hz, the 1746-IA16’s vibration rating is 1G.
