The 1746-IC16 SLC 500 Sinking DC input Module by Allen-Bradley is a 48V DC sinking module with 16 sinking inputs that uses a Removable Terminal Block (RTB). Its temperature-dependent voltage ranges between 30 and 60V DC sinking at 55°C and between 30 and 55V DC sinking at 60°C. The 1746-IC16 has a backplane draw current of 0.085A at 5V DC and one of 0A at 24V DC.
The electrical signal in the input points has a maximum delay time of 4ms for both the ON and the OFF condition. The 1746-IC16 has an OFF-state voltage loss of 10V DC, a current leakage of 1.5mA, and the nominal current on the overall inputs is 4.1mA at a nominal module voltage of 48V DC. It provides a circuit isolation between the backplane and the inputs at 1500V AC tested for 60s and it has a dielectric withstand of 1500V AC.
The 1746-IC16’s operating temperature range is between 0 and 60 °C (32 and 140 °F) at 5-95% relative humidity. Its non-operational storage temperature ranges between 40 and 85 °C (-40 and 185 °F). The 1746-IC16 has an operational shock of 30G (3 directional pulses for 11ms) and it can withstand a vibration of 1.0G at 5-200Hz.
Part Number: | 1746-IC16 | |
Signal delay: | 4 milliseconds | |
Off State Current: | 1.5 milliamps | |
Applications: | General Purpose 48 Volts DC Inputs | |
I/O Connection: | 1746-HT and 1746-HCA | |
Step Response: | 100 milliseconds in, 2.5 milliseconds out |
Allen Bradley 1746-IC16
1747-L514 | Allen Bradley | SLC 500 Modular Hardware Style
Email:sales3@amikon.cn
Part Number: |
1746-IC16 |
Module Type: |
Digital DC Input Module |
Series: |
SLC 500
|
Voltage Range: | 30-55 Volts DC Sink |
Backplane Current (5 Volts DC): |
85 |
