Technical Specifications for 1746-IC16
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Backplane Current
|
85
|
|
Part Number/Catalog No.
|
1746-IC16
|
Input Voltage
|
30-55 Volts
|
|
Module Type
|
Input Module
|
Power Dissipation
|
5.5 Watts
|
|
Manufacture Year
|
2022
|
Current range
|
4-28 mA
|
|
Product Package
|
Original Package
|
UPC
|
10662462687062
|
About 1746-IC16
|
The 1746-IC16 has an OFF-state voltage loss of 10V DC, a current leakage of 1.5mA, and the nominal current on the overall inputs is 4.1mA at a nominal module voltage of 48V DC. It provides a circuit isolation between the backplane and the inputs at 1500V AC tested for 60s and it has a dielectric withstand of 1500V AC.
The 1746-IC16 has a backplane draw current of 0.085A at 5V DC and one of 0A at 24V DC. The electrical signal in the input points has a maximum delay time of 4ms for both the ON and the OFF condition.The 1746-IC16 SLC 500 Sinking DC input Module by is a 48V DC sinking module with 16 sinking inputs that uses a Removable Terminal Block (RTB).
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
