Technical Specifications for 1746-IH16
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Voltage Range
|
90-146 Volts DC Sink
|
|
Part Number/Catalog No.
|
1746-IH16
|
Inputs
|
16
|
|
Module Type
|
Current Sinking DC Input Module
|
I/O Connection
|
1746-HT and 1746-HCA
|
|
Manufacture Year
|
2021
|
Signal delay
|
9 milliseconds
|
|
Product Package
|
Original Package
|
Off State Current
|
0.8 milliamps
|
About 1746-IH16
|
The 1746-IH16 has a maximum OFF state drop voltage of 20V DC and a current leakage of 0.8mA in its OFF state. It nominal input current per point is 2.15mA at 125V DC and 2.25mA at 132V DC and the module has an overall heat dissipation of 5.17W. It is stored at a temperature ranging between -40 and 85 °C (-40 and 185 °F) and it operates well in a temperature range of 0-60 °C (32-140 °F) at 5-95% non-condensing humidity condition.
The 1746-IH16 has an operational shock rating of 30G with an operational vibration of 2.5G at 57-200 Hertz and a NEMA standard ICS 2-230-rated Noise immunity. It offers circuit isolation between the inputs and control logic and is C-UL and CSA-certified.
The 1746-IH16 SLC 500 General Purpose 125V DC Input Module, is a current sinking digital input module by which comes with a Removable Terminal Block and can be installed on any free 1746 I/O chassis slot. It is an input module with 16 current sinking 125V DC inputs and 16 points per common.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to repair.
