The Allen-Bradley SLC 500 is a small chassis-based family of programmable controllers, discrete, analog, and specialty I/O, and peripheral devices. The SLC 500 family delivers power and flexibility with a wide range of communication configurations, features, and memory options. The RSLogix 500 ladder logic programming package provides flexible editors, point-and-click I/O configuration, and a powerful database editor, as well as diagnostic and troubleshooting tools to help you save project development time and maximize productivity.



The 1746-NIO4I analog combination module contains 2 inputs (-+10V DC, - +20mA), 2 outputs (0...20mA). The backplane current load of 1746NIO4I is 55mA at 5V DC or 145mA at 24V DC. This analog combination module houses a resolution (bits), max. of 16 bits in 14 bits out. 1746-NIO4I contains a bandwidth of 10Hz and step response at 95% of 60ms in 2.5ms out.



1746-NIO4I
Full Scale 20 mA
Input Range ±20 mA (nominal)
±30 mA (maximum)
Current Input Coding ±16,384 for ±20mA
Absolute Maximum Input Voltag 2.5V dc or 7.5V ac RMS
Input Impedance Resolution 250 Ω (nominal)
1.22070 μA per LSB
Overall Accuracy  ±0.365% of full scale
at 25 °C (77 °F)
Overall Accuracy,  ±0.642% of full scale (maximum)
0…60 °C (32…140 °F)
Overall Accuracy Drift +79 ppm/°C of full scale
Gain Error at  +0.323% (maximum)
25 °C (77 °F)



Allen Bradley  1746-NIO4I


1746-NIO4I | Allen Bradley |  analog combination module




Email:sales3@amikon.cn



Cat. No. Description Voltage Category
1746-NIO4I High Resolution Analog Input,Analog Current -20…+20 mA (or) -10…+10V dc (Inputs)
Output Module 0…20 mA (Outputs)
