The Allen-Bradley 1746-OA16 is an SLC 500 Digital AC Output Module with an operating voltage of 85 - 265V AC at 47 - 63 Hz. It has 16 outputs with 8 points per common group. It requires a backplane current load of 0.37 A at 5V DC and it has a maximum signal delay of 1ms at On-state and 11ms at Off-state. The 1746-OA16 has maximum continuous current per point and per module of 0.5 A and 8 A respectively at 30 °C (86 °F) and of 0.25 A and 4 A respectively at 60 °C (140 °F). It is used in the general-purpose 120-240V AC outputs of SLC 500 systems.
The 1746-OA16 module receives and stores digitally-converted analog data in its data image table where it can be retrieved by all modular and fixed SLC 500 processors. It supports connections from up to eight sensors or actuators. The 1746-OA16 comes with removable terminal blocks that eliminate the need to disconnect wires when replacing any of the modules. The 1746-OA16 also includes filter circuitry and optical coupling for signal noise reduction.
|
Attribute
|
|
1746-OA16
|
|
|
|
|
|
Voltage category
|
|
120/240V AC signal input
|
|
|
|
|
|
Number of outputs
|
|
16
|
|
|
|
|
|
Points per common
|
|
8
|
|
|
|
|
|
Voltage, operating
|
|
85...265V AC @ 47...63 Hz
|
|
|
|
|
|
Backplane current
|
|
0.370 A
|
|
consumption
|
|
|
|
|
|
|
|
Signal delay, max resistive load
|
|
On = 1 ms
|
|
|
|
Off = 11.0 ms
|
|
|
|
|
|
Off-state leakage, max
|
|
2 mA
|
Allen Bradley 1746-OA16
1746-OA16 | Allen Bradley | SLC 500 Digital I/O Module
Email:sales3@amikon.cn
Part Number:
|
1746-OA16
|
|
Series:
|
SLC 500
|
|
Module Type:
|
Digital AC Output Module
|
|
Voltage Range:
|
85-265 Volts AC
|
|
Outputs:
|
16
|
