Technical Specifications for 1746-OA8
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Input Frequency
|
47 to 63 Hertz
|
|
Part Number/Catalog No.
|
1746-OA8
|
Input Voltage
|
85-265 Volts AC
|
|
Module Type
|
Output module
|
Power Dissipation
|
57-106 Watts
|
|
Manufacture Year
|
2022
|
Output Current
|
185 mA
|
|
Product Package
|
Original Package
|
UPC
|
10662073521331
|
About 1746-OA8
|
The 1746-OA8 has a maximum leakage current of 2mA in its OFF state and the minimum current load on each output point is 10mA. The maximum current on each output point is 1A which falls to 0.5A at 60 °C and the aggregate current on the 1746-OA8 module is 8A but it can fall to 4A at 60 °C. It has a drop voltage of 1.50V at 1A in its OFF state and the module has an output current surge of 10A for 25ms.
The 1746-OA8 is an SLC 500 AC output module. This module is part of discrete output modules, used to energize electrical loads that operate at an operating voltage range of 85-264 VCA with frequency of 47-63 Hz. The module’s nominal output voltages are 120VAC and 240VAC and occupies a single slot of the 1746 chassis.
|
