1746-OAP12 | Allen-Bradley | Output Module

1746-OAP12   SLC High Current Output Module



Allen  Bradley    1746-OAP12  !!!  --- sales3@amikon.cn



  Contact:  Jessica

                               Email:  sales3@amikon.cn

                               Skype:  jessica01235483

                               Wechat:  hu18030235311

                               Mobile:  86-18030235311(WhatsApp)








The 1746-OAP12 SLC 500 Digital Output Module by Allen-Bradley is an AC output module fitted in any slot of the 1746 Chassis and it comes with a Removable Terminal Block (RTB). It has 12 outputs with 6 output points per electronically-fused common. The 1746-OAP12 has 120-240V AC of output voltage category and it has a module voltage range between 85 and 265V AC at 47-63Hz. The module has a backplane current of 0.370A at 5V DC voltage and it reaches 0A at 24V DC.




The 1746-OAP12 has an output signal delay time of 11ms for OFF mode and 1ms for ON mode and the maximum leakage current on its output in its OFF state is 2mA. The lowest possible current load on each output point is 10mA, and the normal current on each point is 2A at 30 °C (86 °F) and 1A at 60 °C (140 °F).




The 1746-OAP12 module has a total output current of 9A at 30 °C (86 °F) and it has a voltage loss of 1.2V DC at 2.0A. It has a surge current of 17A for 25ms repeatable every 2 seconds at 60 °C on each point and it has a surge of 35A per common for 10ms.




The 1746-OAP12 has a maximum 1AW heat dissipation on each point and an overall module heat dissipation of 10.85W. Its operating temperature ranges between 0 and 60 °C (32 and 140 °F) at 5-95% relative humidity without condensation. The 1746-OAP12has an operational shock rating of 30G and a vibrational withstand of 5G at 10-500Hz.









Specifications 1746-OAP12
Number of outptus 12
Points per common 6
Voltage category 120/240V AC
Operating voltage range 85…265V AC @ 47…63 Hz
Backplane current (mA) @ 5V 370 mA
Backplane current (mA) @ 24V 0 mA
Voltage drop, on-state output, max 1.2V @ 2.0 A
Load current, min 10 mA
Leakage current, off-state output, max 2 mA
Surge current per point, max 17.0 A for 25 ms(








Allen  Bradley  1746-OAP12


1746-OAP12 | Allen-Bradley | Output Module





Email:sales3@amikon.cn





  Part Number:
  1746-OAP12
  Module Type:

  Digital AC Output Module

  Series:

  SLC 500

  Voltage Range:   85-265 Volts AC
  Current/Output at 30 Celsius:

  2 amps
