Technical Specifications for 1746-OB16E
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Power Consumption
|
6.2 Watts
|
|
Part Number/Catalog No.
|
1746-OB16E
|
Current
|
0 to 25 mA
|
|
Module Type
|
Digital Output Module
|
Backplane Current
|
135 milliamps
|
|
Manufacture Year
|
2022
|
Input Voltage
|
10-30 Volts DC
|
|
Product Package
|
Original Package
|
UPC
|
10662072720414
|
About 1746-OB16E
|
The 1746-OB16E has 0.388W heat dissipation per output point and 7.6W of aggregate heat dissipation on the module. It has an operating temperature bracket of 0-60 °C (32-140 °F) at a relative humidity condition of 5-95% without condensation and it is NEMA ICS 2-230 rated for Noise immunity. The 1746-OB16E has an operational vibration of 2.5G at 10-200Hz and a shock rating of 30G.
The 1746-OB16E has a load-dependent 1ms signal delay time for both ON and OFF mode and it has a maximum output current leakage of 1mA in its OFF state. The minimum current load available on each point is 1mA and it has an inrush current 2.0A on each point for 2ms repeating every 1s at 30 °C (86 °F).
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
