1746-P2 | Allen Bradley | Power Supply

1746-P2  Power Supply has an Input Voltage of 120/220 Volts AC



Allen Bradley   1746-P2  !!!  ---mail to: sales3@amikon.cn



  Email:     sales3@amikon.cn

                                                                     Contact:  Jessica                   |   Skype:     jessica01235483

                                                                     Wechat:   hu18030235311    Mobile:   86-18030235311(WhatsApp)







The Allen-Bradley 1746-P2 is an SLC 500 modular power supply. It comes with an input voltage of 85-132 or 170-265V AC at 47-63 Hz. Its internal current capacity at 5V is 5 A and it is 0.96 A at 24V. This power supply also comes with a maximum user-supplied overcurrent protection of 15 A and a maximum inrush current of 20 A. It has a 180 VA typical line power requirement and an input terminal and backplane isolation of 1800V AC RMS for 1 s. User-power current capacity at 24V DC is 200 mA and the user-power voltage range of the power supply, also at 24V DC, is 18-30V DC.


It has a maximum of two AWG wires per terminal. Fuse protection is present with the 1746-P2 power supply but it is limited to guarding against fire hazards due to short-circuit conditions. It comes with an open-type enclosure and can only be installed in a 1746 chassis. The entire power supply measures 5.5 x 2.9 x 5.7 inches and weighs 1.1 kg or 2.5 lbs. Its operating temperature is from 0-60 ËšC.




Allen Bradley    1746-P2

1746-P2 | Allen Bradley | Power Supply




         sales3@amikon.cn




For overcurrent conditions, the 1746-P2 Series A and B will undergo a power supply shutdown and CPU fault. The recovery procedure is to reload the user program. For the 1746-P2 Series C, it will have a 24V DC user shutdown but the CPU continues its operation and the recovery procedure is to correct the overcurrent condition.
