The Allen-Bradley 1747-ACN15 ControlNet™ adapter module comes with remote control 1746 I/O on the ControlNet network. The 1747-ACN15 is capable of high-speed data transfer and diagnostic messages. The Allen-Bradley 1747-ACN15 has local communication network access through its network access port or NAP. This module has 1 ControlNet connector, 1 ControlNet status indicator, and module net address switch assemblies at the top of the module.
The 1747-ACN15’s health indicator is located on the adapter module’s front panel. It shows normal operating conditions and errors on the remote I/O system. The alphanumeric view (address/net status) in this module gives an indication of a status code if an error occurs during initialization or operation. The full description of the diagnostic indicator, the status display, and how to use them for troubleshooting are explained in the user manual.
The 1747-ACN15 adapter module needs a maximum backplane current of 900 mA at 5V DC. Remember to add this quantity to the different flow necessities in your I/O chassis. You can attach your 1747-ACN15 adapter module to the ControlNet network through 4 available taps. Please do not permit steel elements from the tap to touch any conductive material. If you dispose of the tap from the adapter, do not forget to replace the dirt cap on the straight-angle or direct-line connectors. This is to prevent accidentally touching the surface of the steel-based soil.
|
Cat. No.
|
|
1747-ACN15
|
|
|
|
|
|
Description
|
|
Single-port non-redundant-media/redundant-media ControlNet I/O adapter module
|
|
|
|
|
|
Ports
|
|
ControlNet I/O adapter port
|
|
|
|
|
|
Communication Rate
|
|
5 Mbit/s
|
|
|
|
|
|
Connectors
|
|
•1 BNC connector for non‐redundant media operation
|
|
|
|
•1 NAP (RJ‐45 8‐pin with shield)
|
|
|
|
|
|
Cable
|
|
Quad-shield RG-6 coaxial cable
|
|
|
|
|
|
Backplane Current Load
|
|
900 mA at 5V DC
|
|
|
|
|
|
Weight
|
|
0.2 kg (0.4 lb)
|
|
|
|
|
|
Operating Shock
|
|
30 g (3 pulses, 11 ms)
|
|
|
|
|
|
Nonoperating Shock
|
|
50 g (3 pulses, 11 ms)
|
Allen Bradley 1747-ACN15
1747-ACN15 | Allen Bradley | SLC 500 I/O Adapter Module
Email:sales3@amikon.cn
Part Number:
|
1747-ACN15
|
|
Series:
|
SLC 500
|
|
Module Type:
|
I/O Adapter Module
|
|
Communication Port:
|
ControlNet I/O Adapter
|
|
Communication Rate:
|
5 Megabits/Second
|
