Brand Name                 AB

Product reference      1756-A13

The Allen-Bradley 1756-A13 is a ControlLogix I/O Chassis-Based Module. It has a 13-slot ControlLogix Chassis, a 6.1 W Power dissipation, and a 1.8 W power consumption. It has dimensions of 23.15 x 6.65 x 5.71 in. and a weight of 4.2 lbs. It is horizontally-mounted inside the panel and has an open-style enclosure. It has a maximum Backplane current of 1.5 A at 1.2V DC, 4 A at 3.3V DC, 15 A at 5.1V DC, and 2.8 A at 24 V DC. For communication, it uses the ControlNet or the EtherNet/IP networks.

The 1756-A13 Standard Chassis includes time-stamping capabilities for SOE applications. The chassis backplane distributes power to each of the modules within the chassis by providing a high-speed communication path between modules. It needs a Bulletin 1492 IFM or an RTB to connect all the field-side wiring. For programming, it uses Studio 5000 Logix Designer Application software. The software includes I/O wizards for simple module configuration.

The 1756-A13 Standard Chassis provides easy maintenance with the Removal and Insertion Under Power (RIUP) feature. For preventing replacement errors, it also offers electronic keying. In case of any system or field side failure, its comprehensive diagnostic feature helps identify the fault. It is compact, cost-effective, and easily compatible with items such as a PanelView operator.

The ControlLogix® architecture provides a wide range of input and output modules to span many applications, from high-speed digital to process control. The ControlLogix architecture uses Producer/Consumer technology, which allows input information and output status to be shared among multiple ControlLogix controllers. Each ControlLogix I/O module mounts in a ControlLogix chassis and requires either a removable terminal block (RTB) or a 1492 interface module (IFM) to connect all field-side wiring. RTBs and IFMs are not included with the I/O modules. They must be ordered separately
