The Allen-Bradley 1756-EN2T is a part of the ControlLogix Communication Module series. It is an EtherNet/IP (Ethernet Industrial Protocol) interface communication module. It supports general messaging, real-time I/O messaging, and information exchange for applications like Real-Time Control, Time Synchronization, and Motion. The 1756-EN2T also has the CIP safety standard by allowing simultaneous transfer of safety and control data and diagnostics information. It uses advanced communication chips and physical media.
The 1756-EN2T Module has 10 - 100 Mbps EtherNet/IP communication rates and uses copper. It supports 256 Logix and 128 TCP/IP communication connections. It can support a maximum of 8 axes for integrated motion on the Ethernet/IP Network and draws 1 A current at 5.1V DC. It has a maximum power dissipation of 5.1 W and thermal dissipation of 17.4 BTU/hr. It can be installed in any slot in the ControlLogix Chassis. For wiring, it uses unshielded RJ45, category 5, twisted-pair cable connectors to interface with the controller. The 1756-EN2T is configured using RSLinx software to be used at the workstation. To operate an EtherNet/IP network, parameters such as an IP address, Subnet masks, Gateway, etc. must be defined.
The 1756-EN2T bridge has various functions like providing support for messaging, distributed I/O, and tags. It encapsulates messages within standard TCP/IP protocol. ControlNet and DeviceNet network protocols allow it to share a common application layer. It does not require any scheduling or routing table to store information. Other features include explicit protected mode, electronic keying, a device level ring network, and parallel redundancy protocol network support.
|
Attribute 1756-EN2T
|
|
1756-EN2T
|
|
|
|
|
|
Enclosure type rating
|
|
None (open-style)
|
|
|
|
|
|
Module location
|
|
Any slot in the ControlLogix chassis
|
|
|
|
|
|
Backplane current
|
|
1 A at 5.1V DC
|
|
|
|
|
|
Backplane current
|
|
3 mA at 24V DC
|
|
|
|
|
|
Isolation voltage
|
|
30V (continuous), Basic Insulation Type, Ethernet to
|
|
|
|
backplane
|
|
|
|
No isolation between USB and backplane
|
|
|
|
Type tested at 510V AC for 60 s
|
|
|
|
|
|
Power dissipation, max.
|
|
5.1 W
|
Allen Bradley 1756-EN2T
1756-EN2T | Allen Bradley | ControlLogix Ethernet Communication Module
Email:sales3@amikon.cn
Part Number:
|
1756-EN2T
|
|
Series:
|
ControlLogix
|
|
Module Type:
|
Ethernet Communication Module
|
|
Ethernet-IP Communication Rate:
|
10-100 Megabites per second
|
|
Insulation Voltage:
|
30 Volts Continuous
|
