1756-IB32 | Allen Bradley | ControlLogix Digital I/O Modules 1756-IB32/B

1756-IB32  ControlLogix 32 Pt 12/24V DC D/I Module



Allen Bradley   1756-IB32  !!!  --- sales3@amikon.cn


Contact:Jessica

Email:sales3@amikon.cn

Skype:jessica01235483

Wechat:hu18030235311

Mobile:86-18030235311(WhatsApp)







The ControlLogix® architecture provides a wide range of input and output modules to span many applications, from high-speed digital to process control. The ControlLogix architecture uses Producer/Consumer technology, which allows input information and output status to be shared among multiple ControlLogix controllers.



ach ControlLogix I/O module mounts in a ControlLogix chassis and requires either a removable terminal block (RTB) or a 1492 interface module (IFM) to connect all field-side wiring. RTBs and IFMs are not included with the I/O modules. They must be ordered separately.




Number of Inputs  32 (16 points/common)
Module Location  1756 ControlLogix Chassis
Backplane Current  120mA @ 5.1V dc & 2mA @ 24V dc
Backplane Power  0.66W
On-State Voltage Range  10-31.2V dc
Nominal Input Voltage  24V dc
Isolation Voltage  250V maximum continuous
            Group to group  100% tested at 2546V dc for 1s
            User to system 250V maximum continuous
100% tested at 2546V dc for 1s



Allen Bradley   1756-IB32 | 1756-IB32/B


1756-IB32 | Allen Bradley | ControlLogix Digital I/O Modules




Email:sales3@amikon.cn




  Inputs
  32 (16 points/group)
  Voltage category
  12/24V DC sink
  Operating voltage range
  10…31.2V DC
  Input voltage, nom
  24V DC






HOT SALE --- please contact us !!!



1756-IB32 ControlLogix 32 Pt 12/24V DC D/I Module
1756-IB32-CC Conformal Coated 1756-IB32
1756-IC16 ControlLogix 16 Pt 48V DC D/I Module
1756-IC16-CC Conformal Coated 1756-IC16
1756-IF16 ControlLogix 16 Pt A/I Module
1756-IF16-CC Conformal Coated 1756-IF16
1756-IF16H-CC Conformal Coated 1756-IF16H
1756-IF4FXOF2F ControlLogix 6 Point Analog Comb Module
1756-IF4FXOF2F-CC Conformal Coated 1756-IF4FXOF2F
1756-IF6CIS ControlLogix 6 Point A/I Module
1756-IF6CIS-CC Conformal Coated 1756-IF6CIS
1756-IF6I ControlLogix 6 Point Isolated A/I Module
1756-IF6I-CC Conformal Coated 1756-IF6I
1756-IF8 ControlLogix 8 Point A/I Module



Email:sales3@amikon.cn




if you have a large purchase, we can make a discount.
specifications:

new+original +one year warranty
