has a nominal input voltage of 48V DC and a similar voltage category, at 48V DC sink. Its operating voltage range varies depending on the temperature; at 60 Degrees Celsius, it ranges from 30 to 55V DC and at 55 Degrees Celsius, it goes from 30 to 60V DC.
|
|
1756-IB16ISOE Description:
|
The backplane current of this module at 5.1V is 100 mA, while at 24V, it is 3 mA. For the current during an on-state, it has a minimum of 2 mA at 30V and a maximum of 7 mA at 60V
|
|
maximum power dissipation of 5.2W at 60 Degrees Celsius and a maximum thermal dissipation of 17.73 BTU/hr. It also has a maximum inrush current of 250 mA.
|
|
The input delay time for Off-to-On and On-to-Off differ. For Off-to-On, there is a hardware delay of up to 1 ms plus a user-configurable filter time of either 0, 1, or 2 ms.
|
|
