1756-IF16 | Allen Bradley | Analog Input Module

Allen Bradley   1756-IF16   !!!  ---mail to: sales3@amikon.cn

  Email:     sales3@amikon.cn

                                                                     Contact:  Jessica                   |   Skype:     jessica01235483

                                                                     Wechat:   hu18030235311   |  Mobile:   86-18030235311(WhatsApp)

The Allen-Bradley 1756-IF16 is a non-isolated analog current/voltage I/O module. In order to connect to a ControlLogix chassis, it requires an RTB, or a removable terminal block housing, of either the 1756-TBS6H or 1756-TBCH. This input module has 16 points available.

These points allow users to wire the module in different ways, unlike other modules. The 1756-IF16 can be wired using three different methods, depending on the user's and application's requirements: single-ended wiring, differential wiring, and high-speed mode differential wiring. The single-ended wiring method is best when all input devices are tied to a common ground.

Allen Bradley    1756-IF16

1756-IF16 | Allen Bradley | Analog Input Module

         sales3@amikon.cn

The Voltage power dissipation is around 2.3 Watts and the current power dissipation is 3.9 Watts. The thermal dissipation for the voltage is 7.84 BTU/hour and 13.3 BTU/hour for current. It also has a maximum overvoltage protection of 30 Volts DC (voltage) and 8 Volts DC (current).

Emal:sales3@amikon.cn

Shipping Term : TNT,DHL,FEDEX,ETC
Payment Term : T/T

Warranty: 12 month
Amikon supply： New+original+factory sealed+high quality
