Part Number/Catalog No.
|
1756-IV32
|
|
Module Type
|
Digital DC Input Module
|
|
Inputs
|
32
|
|
Input Voltage
|
12-24 Volts DC
|
|
Operating Voltage Range
|
10-30 Volts DC
|
|
Input Delay Time
|
2 milliseconds plus selected filter time
|
|
Minimum Operating Current
|
2 milliamps at 10 Volts DC
|
|
Maximum Operating Current
|
3.5 milliamps at 30 Volts DC
|
|
Maximum Input Current, Off-State
|
1.5 milliamps
|
|
Power Dissipation (Max)
|
4.1 Watts at 60 degrees Celsius
|
|
Backplane Current at 5 Volts
|
120 milliamps
|
|
Backplane Current at 24 Volts
|
2 milliamps
|
|
Removeable Terminal Block(s)
|
1756-TBCH, 1756-TBS6H
|
The 1756-IV32 is a digital input module with 32 inputs, organized into two groups of 16 points each. This module is designed to be installed in a compatible 1756 chassis, and requires a removable terminal block (RTB) for connection. The compatible RTBs are the 1756-TBCH or 1756-TBS6H models. The 1756-IV32 operates with a voltage range of 10 to 30 Volts DC and is a 12/24 Volts DC source module. The current consumption is 120 milliamps at 5.1 Volts and 2 milliamps at 24 Volts. The module has a total backplane power of 0.66 Watts and a nominal input voltage of 24 Volts DC. Its continuous voltage capacity is 250 Volts.
