The Allen-Bradley 1756-L1M3 is a ControlLogix 5550 controller that has a user available memory of 2 Mb and an I/O memory of 150 kb. It does not have a nonvolatile memory nor an enclosure. The 1756-L1M3 controller weighs 0.36 grams or 12.7 ounces and has emissions of Group 1, Class A. This controller has a peak backplane current of 1.20 Amps at 5.1 Volts DC and 0.02 Amps at 24 Volts DC.
It has an average power dissipation of 5.4 Watts and an average thermal dissipation of 18.4 BTU/hour. It also has an isolation voltage of 30 Volts. The 1756-L1M3 has been tested to withstand 500 Volts for 60 seconds. The operating temperature of the 1756-L1M3 controller ranges from 0 to 60 Degrees Celsius, while its storage temperature is from -40 to 85 Degrees Celsius. A noncondensing relative humidity of 5% to 95% exists with this controller.
A vibration of the 1756-L1M3 controller is a 2.0 G maximum peak acceleration at 10 to 500 Hertz. Its operating shock is 30 G peak for 11 milliseconds, while its storage shock is 50 G peak for 11 milliseconds. The 1756-L1M3 controller has an ESD immunity of 6 kilovolts for contact discharges and 8 kV for air discharges
|
1756-L1M3
|
|
|
|
|
|
|
|
user available memory
|
|
2M bytes
|
|
|
|
|
|
nonvolatile memory
|
|
no
|
|
|
|
|
|
peak backplane current
|
|
|
|
+5.1V dc
|
|
1.20A
|
|
+24V dc
|
|
0.02A
|
|
|
|
|
|
average power dissipation
|
|
5.4W
|
|
|
|
|
|
average thermal
|
|
18.4 BTU/hr
|
|
dissipation
|
|
|
|
|
|
|
|
weight
|
|
12.7 oz.
|
|
|
|
|
|
operating temperature
|
|
0° to 60° C (32 to 140° F)
|
|
|
|
|
|
storage temperature
|
|
-40° to 85° C (-40 to 185° F)
|
|
|
|
|
|
relative humidity
|
|
5% to 95% noncondensing
|
Allen Bradley 1756-L1M3
1756-L1M3 | Allen Bradley | ControlLogix Controller and Memory Board
Email:sales3@amikon.cn
Part Number:
|
1756-L1M3
|
|
Series:
|
ControlLogix
|
|
Module Type:
|
Processor Module
|
|
Operating Temperature:
|
32-140 Fahrenheit (0-60 Celsius)
|
|
Minimum Operating Current:
|
2 milliamps at 10 Volts DC
|
