The Allen-Bradley 1756-L55M23 is a ControlLogix Controller in the Logix5000 family of controllers. It has 1.5 KB of data and logic memory, 208 KB of I/O memory, and an integrated nonvolatile backup memory. The 1756-L55M23 has a Logix CPU as well as a backplane CPU to divide its resources. Application codes and messages are executed by the Logix CPU and the backplane CPU sends and receives data from the backplane and it communicates with I/O.




The 1756-L55M23 controller is connected to the workstation or another controller via the serial port. A 1756-CP3 serial cable is used to connect the controller to the workstation. RSLinx software is used to configure the device driver and RSLogix 5000 programming software for selecting the controller path. For communication with other devices, it uses various networks like Ethernet/IP, ControlNet, DeviceNet, etc. The 1756-L55M23 can produce and consume system-shared tags over the EtherNet/IP or the ControlNet networks. One connection each is required for both the producer and the consumer.





The 1756-L55M23 controller has a multitasking feature which lets processing time be allocated to different operations in the application. It also contains programs for the group data and logic. It provides routines for encapsulating executable code in a single programming language. It supports Logix5000 programming languages both online and offline.









Part Number: 1756-L55M23
Backplane Current (5Volts DC): 1.23 Amps
Backplane Current (24 Volts DC): 14 milliamps
Weight: 0.78 pounds (0.35 kilograms)
Operating Temperature : 32-140 Fahrenheit (0-60 Celsius)
Vibration: 10-500 Hertz
Relative Humidity: 5-95 percent
Battery: 1756-BA1 or 1756-BATM








Allen  Bradley   1756-L55M23


1756-L55M23 -  Allen Bradley | ControlLogix Processor Module






Email:sales3@amikon.cn





  Part Number:
  1756-L55M23
  Series:

  ControlLogix

  Module Type:

  Processor Module

  Maximum Analog I-O:
  4,000 Input, 2,000 Output
  Program Scan Time:   0.08 milliseconds
