1756-L73
|
|
Dimensions ：
|
3.8cmx14.2cmx14cm
|
Weight：
|
0.2kg
|
|
The 1756-L73 can use up to 8 MB of user memory with 0.98 MB of Input/Output memory. In addition, it has 128,000 total and digital I/O and 4000 analog I/O at most. The required current draw at 1.2V DC is 5 mA and 800 mA current draw is required at 5.1V DC.
|
|
The 1756-L73 controller has an operating temperature of 0-60 deg. Celsius and its non-operating temperature is -40-85 °. Celsius. The maximum surrounding temperature that it can operate at is 60°. Celsius with 5 - 95% non-condensing relative humidity. Its operating vibration is 10 - 500 Hz is 2 g and its operating shock is 30 g operating shock while its non-operating shock is 50 g.
|
