The 1756-M16SE is an Allen-Bradley ControlLogix SERCOS Integrated Motion Module. This SERCOS interface module is a link between the ControlLogix platform and the intelligent servo drives. The 1756-M16SE is an enclosure-free (open) controller and digital drive interface made for rapid real-time serial communication through its fiber-optic cables which are noise-immune. The 1756-M16SE module is compatible with RSLogix 5000 motion instructions set and with axis configuration utilities.
The 1756-M16SE has 16 axes per module and 32 axes per controller. Its SERCOS data rate is either 4 or 8 Mb/s and its SERCOS cycle time is 1 ms for as many as 4 drives at 4 Mb/s and it is 0.5 ms for as many as 4 drives at 8 Mb/s. The control modes regulate velocity, torque, and precision. The 1756-M16SE’s current draw is 760 mA at 5V DC and 2.4 mA at 24V DC.
The 1756-M16SE interface module uses 1 digital fiber-optic link that eliminates the need for up to 18 digital wires per axis. The user can send detailed drive-status information from the drive to the controller and vice versa. The 1756-M16SE can connect to the following servo drives: the 2093 Kinetix 2000, the 2094 Kinetix 6000, the 2099 Kinetix 7000 high-power servo drive, and the 2098 Ultra3000 SERCOS servo drive.
|
Attribute
|
|
1756-M16SE
|
|
|
|
|
|
Number of drives, max
|
|
16
|
|
|
|
|
|
SERCOS data rate
|
|
4 Mbps
|
|
|
|
8 Mbps
|
|
|
|
|
|
SERCOS cycle time @ 4 Mbps
|
|
0.5 ms, up to 2 drives
|
|
|
|
1 ms, up to 4 drives
|
|
|
|
2 ms, up to 8 drives
|
|
|
|
|
|
SERCOS cycle time @ 8 Mbps
|
|
0.5 ms, up to 4 drives
|
|
|
|
1 ms, up to 8 drives
|
|
|
|
2 ms, up to 16 drives
|
|
|
|
|
|
Drive control modes
|
|
Position, velocity, and torque
|
|
|
|
|
|
Current draw @ 5.1V DC
|
|
760 mA
|
|
|
|
|
|
Current draw @ 24V DC
|
|
2.5 mA
|
|
|
|
|
|
Power dissipation
|
|
5.0 W
|
|
|
|
|
|
Slot width
|
|
1
|
Allen Bradley 1756-M16SE
1756-M16SE | Allen-Bradley | ControlLogix Sercos Servo Module
Email:sales3@amikon.cn
Part Number:
|
1756-M16SE
|
|
Series:
|
ControlLogix
|
|
Module Type:
|
Sercos Servo Module
|
|
Backplane Current (5Volts):
|
760 milliamps
|
|
Backplane Current (24Volts):
|
2.5 milliamps
|
