1756-OA16 | Allen Bradley | Digital AC Output

Allen Bradley   1756-OA16  !!!  ---mail to: sales3@amikon.cn

  Email:     sales3@amikon.cn

                                                                     Contact:  Jessica                   |   Skype:     jessica01235483

                                                                     Wechat:   hu18030235311   |  Mobile:   86-18030235311(WhatsApp)

The Allen-Bradley 1756-OA16 is a 120-240V AC (50-60 Hz) digital output module. It houses 16 mechanically-fused group outputs (8 points per group). The operating voltage range for the 1756-OA16 is 74-265V AC at 47-63 Hz.

The module’s features include individual fault states for each point, Hold the Last State, On-state, Off-state, individual status indications in Program Mode for each point, and mechanically fused groups of outputs. Its output is 3.15A at 250V AC with a slow-blow fuse. Each 1756-OA16 module comes with specific identification information that separates it from other modules. The 1756-OA16 module mounts in a ControlLogix chassis and it uses a 1756-TBNH or 1756-TBSH Removable Terminal Block (RTB) or an Interface Module (IFM) for connecting all the field-side wiring. The 1756-OA16 has no enclosure.

Allen Bradley    1756-OA16

1756-OA16 | Allen Bradley | Digital AC Output

         sales3@amikon.cn

The 1756-OA16’s maximum output current per point is 0.5A and its maximum output current per module is 4A, both at 140oF. It has a maximum power dissipation of 6.5W, also at 140oF. The backplane current is 400 mA at 5V and 2 mA at 24V.

Emal:sales3@amikon.cn

Our company has many products in stock, which are immediately available.

The warranty is 1 years which apply to all the new products.

If you purchase one more parts from us, we can make a discount to you.
