Technical Specifications for 1756-OB32/A
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Power Consumption
|
4.8 Watts
|
|
Part Number/Catalog No.
|
1756-OB32/A
|
Current
|
0 to 25 mA
|
|
Module Type
|
Digital Output Module
|
Relative humidity
|
5 to 95%
|
|
Manufacture Year
|
2022
|
Input Voltage
|
10-31.2 Volts DC
|
|
Product Package
|
Original Package
|
UPC
|
10662468702994
|
About 1756-OB32/A
|
This 1756-OB32 is provided with 32 LED indicators that is used to monitor channel actuations. This front panel indicators are important visual troubleshooting tool as it may be used to confirm the controller’s command to the connected load. Each channel has individual configurable parameters and support output forcing. This module only supports sourcing configuration.
The 1756-OB32 module has a voltage category of 12/24V DC source and an operating voltage range of 10 to 31.2V DC. Its current draw at 5.1V DC is 300 mA and at 24V, it has a current draw of 2 mA. It also has a total backplane power of 1.58W, a maximum off-state leakage current per point of 0.5 mA per point, and a maximum on-state voltage drop of 200 mV DC at 0.5 A.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
