This manual describes how to install, configure, program, and operate a
CompactLogix™ system. This manual is for automation engineers and control
system developers who design, program, and commission 1768 CompactLogix
control systems.
CompactLogix 1768-L43 and 1768-L45 controllers are designed to provide a
solution for medium-sized applications.
|
1768 CompactLogix Controller
|
|
Guidelines
|
|
|
|
|
|
1768-L43 and 1768-L45
|
|
The 1768 power supply must be the leftmost module in the 1768 backplane.
|
|
|
|
The controller must be the rightmost module in the 1768 backplane.
|
|
|
|
Up to two 1768 communication modules can reside between the controller and power
|
|
|
|
supply in any one of these combinations:
|
|
|
|
• 1768-ENBT or 1768-EWEB for EtherNet/IP communication (maximum of two)
|
|
|
|
• 1768-CNB or 1768-CNBR for ControlNet communication (maximum of two)
|
You need these parts when installing your controller:
• 1768-L43 or 1768-L45CompactLogix controller
• 1768-PA3 or 1768-PB3 power supply
• 1769-ECR end cap
• Mounting screws (M4 or #8 panhead) or one of these EN 50 022 DIN
rails:
– 35 x 7.5 mm (1.38 x 0.30 in.)
– 35 x 15 mm (1.38 x 0.59 in.)
• 1756-CP3 serial cable (or make your own)
Allen Bradley 1768-L43/B
AB 1768-L43
Email:sales3@amikon.cn
The CompactLogix controllers support the following:
• 1768-L43, a maximum of 16 local 1769 I/O modules
• The 1768-L43 controller supports 16 tasks, only 1 of which can be
continuous.
• The 1768-L43 controllers offer one built-in serial port and have a
key on the front panel so that you can change controller modes.
