1769-IQ32T/AB IN STOCK& READY FOR SHIP

Contact: Miya

Job Title: Sales Manager

Skype: live:miyazheng520

Email: sales@amikon.cn

Tel: 86-18020776792(Whats App )

QQ :2851195450

Brand Name                 AB

Product reference      1769-IQ32T

Allen Bradley CompactLogix 32 PT. 24 DC Power Input - Single Wide I-O Module. RSLogix5000 | Series A&B |copper wire type. The 1769-IQ32T has an operating voltage range of 20.4-26.4V DC at 60 °C (140 °F). Its minimum on-state voltage is 19V DC and its maximum inrush current is 5 mA. It has a Type 1+ IEC input compatibility with an open-style enclosure type rating. Weighs 2lbs and is 8x8x5 inches.

The Allen-Bradley 1769-IQ32T is a compact 24V DC-rated sink/source terminated input module. It is part of the 1769 Compact I/O Module series. It comes with 32 terminated inputs with eight points per group. The 1769-IQ32T has an operating voltage range of 20.4-26.4V DC at 60 °C (140 °F). Its minimum on-state voltage is 19V DC and its maximum inrush current is 5 mA. It has a Type 1+ IEC input compatibility with an open-style enclosure type rating.
The 1769-IQ32T Compact Input Module can be DIN rail or panel-mounted and it can be assembled with an adjacent I/O module or attached to the controller before or after mounting. It should be installed 8 modules away from the power supply. Its tongue-and-groove slots serve as guides for assembling. This mechanism also secures the modules together. To ensure proper electrical connection and allow communication between the 1769-IQ32T and controller, move the bus lever to the leftmost side until it clicks. Make sure that the lever is locked in place for consistent connectivity.
The DC Digital 1769-IQ32T is designed for use in an industrial environment and should be mounted to a well-grounded surface. This product is shipped with removable write-on terminal labels that can be used for easy identification of parts. These ID tags will be visible even when the module door is closed. For safety, shut off the power when wiring, inserting, and removing the 1769-IQ32T.

The 1769 Compact I/O™ modules can be used in the following applications:

• With a CompactLogix™ controller

• For expansion I/O in a MicroLogix™ 1500 controller assembly

• In an assembly with a 1769-ADN DeviceNet adapter

• In an assembly with a 1769-AENTR Ethernet adapter. Unless connected to a MicroLogix 1500 base, each bank of I/O modules must include its own power supply. Install the I/O modules on a panel with two mounting screws or on a DIN rail. The modules mechanically lock together with a tongue-and-groove design and have an integrated communication bus that is connected from module to module by a moveable bus connector.

Analog I/O Modules Choose analog, thermocouple, or RTD modules for these features:

• Individually configurable channels

• Ability to enable and disable channels individually

• Onboard scaling

• Auto calibration of inputs

• Online configuration

• Selectable input filters

• Over-range and under-range detection and indication

• Selectable response to a broken input sensor

• Selectable power source

• Input modules offer both single-ended or differential inputs

• Ability to direct output device operation during an abnormal condition

• High accuracy ratings The data can be configured on board each module as:

• Engineering Units in volts or milliamps.

• Scaled-for-PID. • Percent of range.

• Raw/Proportional Data for maximum resolution.
