Technical Specifications for 1769-L18ER-BB1B
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Storage Temperature
|
-40 to 85 C
|
|
Part Number/Catalog No.
|
1769-L18ER-BB1B
|
Output Current
|
12.5A
|
|
Module Type
|
Processor Module
|
Input Voltage
|
24 VDC
|
|
Manufacture Year
|
2022
|
Memory
|
512KB
|
|
Product Package
|
Original Package
|
UPC
|
10885630101221
|
About 1769-L18ER-BB1B
|
The 1769-L18ER-BB1B is specially designed to support the user needs ensuring high performance and a cost competitive motion solution. Before deployment of the module, it is important to check the controller memory estimator to make sure there is enough memory to execute the controller program for the application.
The 1769-L18ER-BB1B features a 0.5 MB user memory. It has an internal energy storage that eliminates the need for an additional battery. In addition, the 1769-L18ER-BB1B can read Relay Ladder, Structured Text, Function block, and SFC programming languages. The operating temperature should be between -20 to 60 degrees Celsius (-4 to 140 degrees Fahrenheit) with an IEC 60068-2-30 non-condensing relative humidity between 5 and 95% for optimal controller performance and product life.
The 1769-L18ER-BB1B primary features an embedded user memory amounting to 0.5 MB and a 1GB non-volatile memory that is provided by the pre-installed 1784-SD1 Secure Digital (SD) card. This non-volatile memory may be replaced and upgraded to 2GB memory with the use of the 1784-SD2. Aside from the built-in memory areas.
|
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS
Payment : 100% advance payment bank wire transfer
Returns : If the product has quality problems within one year from the date of receiving the product, you can send it back to replace.
