1746-P1 Power Supply Rack Module
Condition: 100% New Original
Payment Terms: T/T (Bank Wire Transfer)
Minimum Order Quantity: 1pc
Weight: 3.24kg
Dimensions: 19cm x 32.5cm x 11cm
Product Description
The 1746-P1 is SLC 500 controllers continue to operate (hold-up) for a short period of time if the input voltage to the power supply drops below the recommended operating voltage range.
The controller continues to scan the user program and control I/O during this time.
General Specifications
|
Attribute
|
Product Model
|
|
1746-P1
|
|
Line voltage
|
85...132/170...265V ac 47...63 Hz
|
|
Typical line power
|
135VA
|
|
Inrush current, max
|
20 A
|
|
Internal current capacity
|
2 A at 5V dc 0.46 A at 24V dc
|
|
24V dc user-power current capacity
|
200 mA
|
|
Temperature, ambient operating
|
0...60 °C (32...140 °F)
|
|
CPU hold-up time
|
20 ms (full load) 3000 ms (no load)
|
