1771-IBD | Allen Bradley | Input Module

1771-IBD  PLC 5 Digital DC Input Module, 16 Inputs, 10-30 Volts DC Operating Voltage



Allen Bradley   1771-IBD  !!!  ---mail to: sales3@amikon.cn



  Email:     sales3@amikon.cn

                                                                     Contact:  Jessica                   |   Skype:     jessica01235483

                                                                     Wechat:   hu18030235311    Mobile:   86-18030235311(WhatsApp)







The Allen-Bradley 1771-IBD is a PLC 5 Digital DC Input Module. It converts DC signals provided by user devices to the logic level needed by the processor. It directly controls the state of corresponding bits in the PLC data table. It provides a modular design with space-saving and pocket-friendly means to add input to a PLC control system. It comes with a 1771-WH wiring arm to replace the module, eliminating the need to disconnect the wiring.


The 1771-IBD module has 16 inputs with a 10 – 30V DC Sink (Source load) voltage category. It has an operating voltage range of 10 - 30V DC. It has a typical signal delay of 1.3ms (±0.1) at On-DC state and 1.3ms (±0.1) at Off-DC state. It has a maximum Off-state current of 2mA and a backplane current load of 130mA.




Allen Bradley    1771-IBD

1771-IBD | Allen Bradley | Input Module




         sales3@amikon.cn



The 1771-IBD module has 1 green status indicator and 16 red status indicators for customer-side indication at the front panel. It contains optoelectrical isolation to protect the system circuits from electrical transients. It also contains input filtering feature to reduce electrical noise.
