Technical Specifications for 1771-OG
|
Manufacturer
|
Automation
|
|
Condition
|
100% New Original
|
|
Brand
|
|
Backplane Current
|
168 Miliamperes
|
|
Part Number/Catalog No.
|
1771-OG
|
Operating Voltage
|
5.0-5.3 Volts
|
|
Module Type
|
Digital Output Module
|
Input Voltage
|
5.0-5.3 Volts
|
|
Manufacture Year
|
2021
|
Number of Inputs
|
8
|
|
Product Package
|
Original Package
|
UPC
|
10662468205839
|
About 1771-OG
|
The 1771-OG PLC 5 TTL Output Module by is an output module with 8 sinking/sourcing outputs and is located on a slot of the 1771 I/O chassis. It is an output module with an output voltage range of 2-5.25V DC for High = True, and -0.2-0.8V DC for Low = True, and the maximum current on the output is 1mA (source) and 20mA (sink). For transmission of TTL signals, the module requires a separate 5V (+0.25V) DC power supply with a maximum ripple of 50mV peak-to-peak and 250mA current is equally required from the output of the power supply.
The outputs have a maximum signal delay time of 1ms and the module dissipates 2.2W maximum heat with 7.5 BTU/hr maximum thermal dissipation when operational. The 1771-OG comes with a 1771-WC Field wire arm with a wiring arm screw torque of 7-9 inch-pounds and uses a 14 -gauge stranded maximum wire size with 3/64-inch thick insulated Shielded, Belden 8761 wire as circuit conductors.
|
