1771-OG | Allen Bradley | Output Module

Allen Bradley   1771-OG  !!!  ---mail to: sales3@amikon.cn

  Email:     sales3@amikon.cn

                                                                     Contact:  Jessica                   |   Skype:     jessica01235483

                                                                     Wechat:   hu18030235311   |  Mobile:   86-18030235311(WhatsApp)

The 1771-OG PLC 5 TTL Output Module by Allen-Bradley is an output module with 8 sinking/sourcing outputs and is located on a slot of the 1771 I/O chassis. It is an output module with an output voltage range of 2-5.25V DC for High = True, and -0.2-0.8V DC for Low = True, and the maximum current on the output is 1mA (source) and 20mA (sink). For transmission of TTL signals, the module requires a separate 5V (+0.25V) DC power supply with a maximum ripple of 50mV peak-to-peak and 250mA current is equally required from the output of the power supply.

The outputs have a maximum signal delay time of 1ms and the module dissipates 2.2W maximum heat with 7.5 BTU/hr maximum thermal dissipation when operational. The module draws 168mA maximum backplane current from the I/O chassis and it provides circuit voltage isolation tested at 1500V AC (RMS) for 1 second.

Allen Bradley    1771-OG

1771-OG | Allen Bradley | Output Module

         sales3@amikon.cn

The 1771-OG comes with a 1771-WC Field wire arm with a wiring arm screw torque of 7-9 inch-pounds and uses a 14 -gauge stranded maximum wire size with 3/64-inch thick insulated Shielded, Belden 8761 wire as circuit conductors.

Emal:sales3@amikon.cn

All products we sell are 100% New original Package in good condition and will be examed before they are shipped.
